TFT LCD Display Module 2.8 Inch 240x320 RGB Interface TFT LCM Used for Handheld PDA
TFT LCD Display Module 2.8 inch Quick Details
- The ZP28122 is a 2.8 inch diagonal a-Si TFT-LCD display panel product , with an integral WLED backlight system, without backlight driver, without touch screen.
- It features an operating temperature range of -20 ~ 70°C , a storage temperature range of -30 ~ 80°C .
- It's general features are summarized in the following: Portrait type, WLED Backlight, U/D,L/R Reverse, Matte .
- Based on its features, we recommend that this model be applied to Handheld PDA etc.
- Built-in ST7789V driver IC.
TFT LCD Display 2.8 inch Special Features:
| Display Size | 2.8 Inch | Resolution | 240(RGB)x320 |
| Outline Dimension | 50.00x69.20x2.35 mm | Interface | 18 bit RGB Interface |
| Operating Temperature | -20 To 70 ℃ | Viewing Direction | 12 O'clock |
| Storage Temperature | -30 To 80 ℃ | Touch Panel | Without Touch Panel |
| Active area | 43.20x57.60 mm | Driver IC | ST7789V |
| Contrast ratio | 300:1 | Storage Temperature | -30 To 80 ℃ |
| Viewing angle | 80/80/80/80 | Backlight | White LED x 18 |
| Current | 90 mA | FPC Connector | 36 pin |
Panel type: a-Si TFT LCD
Panel size: 2.8 inches
LCD digital: TFT digital
Resolution: 240 (RGB) x 320
Viewing Direction: All view
Brightness: 150cd/㎡ (min.)
TFT outline dimensions: 50.00*69.20*2.35(T)mm (typical)
Active area (H x V): 43.20 * 57.60 mm
Driver IC:ST7789V
Contrast ratio: 300:1 (typical)
Interface: 18 BIT RGB
Display mode: normally white
Surface treatment: anti-glare
Weight: TBD
Operating temperatures: -20 to 70°C
Storage temperatures: -30 to 80°C
Viewing angle: 80/80/80/80° (type) (CRI: ≥10Ra)
Backlight: single LED x4
Compliant with RoHS Directive
Image reversion: up/down and left/right
36-pin interface
TFT LCD Display Module 2.8 Inch 240x320 RGB Interface TFT LCM Applications
Handheld PDA ,Video Door Phone, Digital products , POS machine , instrument & meter , automobile electronics , communication machine , medical machine , security machine , household electrical appliances and others .
Frequently Asked Questions ( FAQ )
Q: What is your Packing term?
A: Protect product with polyfoam and multi layer paper board .
Special protect carton for exporting product .
Per customer requirement .
Q: How about the Delivery term of TFT LCD Display Module?
A:For samples , we will finish production and ship within 7 working days .
We usually arrange DHL , UPS , FedEx express to ship samples .
For bulk orders , usually 30 working days and depends on your design .
We support shipping by air or by sea as per customers' requirements.
Q: Can you support OEM and ODM?
A:We support both standard and customized products and can put your logo on the products .
Our experienced R&D team will support technical questions . ODM and OEM products are warmly welcome .
Q:Why should a client choose your company?
A:We are specialized in offering top quality Mono and TFT LCD solutions.
More than 10 years’ experience in LCD R&D and manufacturing .
Strong R&D term supports perfect custom design services.
Small orders are accepted and welcome.
TFT LCD Display Module 2.8 Inch 240x320 RGB Interface TFT LCM Mechanical Drawing
